Mo10-L6b: What are the Types of Lenses?
Negative Plano-
Meniscus Convex
Lens Lens
Positive Plano-
Meniscus Concave
Lens Lens
A convex lens is curved outward on at least one side When an object is less than one focal length from a
so it is thicker in the middle. convex lens, the image is larger and right side up.
The image formed by a convex lens depends on
where the object is, just like it does for a concave Focal Length
mirror.
Center Thickness Focal Point
Key Concept
What are the Types of Lenses?
How does the image formed by a convex lens
depend on the distance of the object from the
lens?
Focal Length
When an object is farther than one focal length from
a convex lens, the image is upside down.
Focal Length
Focal Point
Convex lens
85
